PRODUCT PARAMETERS


Magnet technology

Flexible pole extension for magnetic field transfer


When to choose flexible pole extensions:

You can use the flexible pole extensions to clamp workpieces with uneven surfaces without deformation and a significant loss of holding force. You can machine the component from 5 sides in one operation. Flexible pole extensions can be adapted to the workpiece shape. They eliminate clamping stress and make it possible to raise the workpiece over the clamping area to allow machining from 5 sides in one clamping operation.

Advantages:

  • Acceleration of work during machining of irregular workpieces
  • Possibility of machining components with uneven surfaces from five sides in one clamp
  • Compensation of workpiece surface irregularities up to 5 mm
  • Elimination of air gaps in irregular components to obtain the maximum holding force

Related products

Help

This product can be rented. Just create an inquiry and check the rent box.

Help

Are you not sure that this product is the right choice? Send us your inquiry and our representatives will be happy to advise you.

Catalog number Pole shoe dimension Height [mm] Availability (approximate) Price without VAT
(valid for EU flag EU only)
TB50FL
50x50 mm 32.00 usually in stock
On request
TB70FL
70x70 mm 45.00 on request
On request

Detailed description:

Flexible pole extensions are able to eliminate irregularities up to 5 mm in size. They make it possible to obtain workpiece flatness without the necessity of using complex bedding. They must be combined with at least 3 fixed pole extensions to create a supporting plane for the workpiece. By using flexible pole extensions, machining efficiency is increased because you can carry out several operations at the same time thanks to the accessibility from 5 sides. Installation or re-arrangement of the extensions on the work surface of the chuck is easily done with screws.

Flexible pole extensions drawing
