Unigrip electromagnetic chuck for standard grinding


Magnetic chucl Unigrip

When to choose the Unigrip electromagnetic chuck:

Unigrip is a universal electromagnetic chuck which, due to an interesting price and holding force of 90 N/cm2, fits in ordinary industrial plants for clamping for everyday grinding of medium to large workpieces.

Advantages:

  • Excellent price-performance ratio
  • High speed of workpiece replacement for efficient production
  • Durable top plate with combined transverse poles allowing versatile utilization when grinding large as well as smaller parts Durable watertight design with firmly embedded coils
  • Standard input voltage 110 V

Related products

Help

This product can be rented. Just create an inquiry and check the rent box.

Help

Are you not sure that this product is the right choice? Send us your inquiry and our representatives will be happy to advise you.

Catalog number Chuck dimension Height [mm] Availability (approximate) Price without VAT
(valid for EU flag EU only)
UNIG200600
200x600 mm 73.00 5 - 6 weeks
On request
UNIG2001000
200x1000 mm 73.00 5 - 6 weeks
On request
UNIG2501000
250x1000 mm 73.00 5 - 6 weeks
On request
UNIG300500
300x500 mm 73.00 5 - 6 weeks
On request
UNIG300600
300x600 mm 73.00 5 - 6 weeks
On request
UNIG300800
300x800 mm 73.00 5 - 6 weeks
On request
UNIG3001000
300x1000 mm 73.00 5 - 6 weeks
On request
UNIG3001500
300x1500 mm 83.00 5 - 6 weeks
On request
UNIG400600
400x600 mm 73.00 5 - 6 weeks
On request
UNIG400700
400x700 mm 73.00 5 - 6 weeks
On request
UNIG400800
400x800 mm 73.00 5 - 6 weeks
On request
UNIG4001000
400x1000 mm 73.00 5 - 6 weeks
On request
UNIG4001500
400x1500 mm 83.00 5 - 6 weeks
On request
UNIG4002000
400x2000 mm 83.00 5 - 6 weeks
On request
UNIG500600
500x600 mm 73.00 5 - 6 weeks
On request
UNIG500800
500x800 mm 73.00 5 - 6 weeks
On request
UNIG5001000
500x1000 mm 73.00 5 - 6 weeks
On request
UNIG5001500
500x1500 mm 83.00 6 - 7 weeks
On request
UNIG5002000
500x2000 mm 83.00 6 - 7 weeks
On request
UNIG6001000
600x1000 mm 73.00 6 - 7 weeks
On request
UNIG6001500
600x1500 mm 83.00 6 - 7 weeks
On request
UNIG6002000
600x2000 mm 83.00 6 - 7 weeks
On request

Detailed description:

Unigrip is an electromagnetic chuck with which you can easily manage general surface grinding. For a favourable price, you get a good holding force, thanks to which you can quickly machine workpieces with different dimensions after clamping.

To make production more efficient, you can use the control unit offers easy activation by pressing the button or regulation of the holding force by turning the potentiometer. This gives you a good holding force in your workshop or industrial manufacturing plant.

Unigrip chucks are constructed for 110 V(DC) and for connection to our control unit with regulation of the holding force and automatic demagnetization.

Important parameters:

  • Application: Grinding
  • Technology: Electromagnet
  • Holding force: 90 N/cm2
  • Min. workpiece size: 25 x 25 x 5 mm
  • Poles: Transverse
  • Regrinding limit: 6 mm
  • Pole pitch: 19 mm, further refined 5+0.5/5+0.5/5+3 steel/brass
  • Guarantee: 2 years

Scope of supply:

  • Magnetic chuck
  • Side and rear stop blocks
  • Set of clamps 3 m power supply cable
  • Certificate
  • Instructions for use

Use:

  • Clamping of medium to large workpieces during general grinding
Výkres Unigrip

Parameters

Model W (mm) L (mm) H (mm) Wattage (W) Weight (kg)
UNIG300600 300 600 73 198 96
UNIG400800 400 800 73 253 162
UNIG3001000 300 1000 73 235 172
UNIG4001000 400 1000 73 384 210
UNIG5001000 500 1000 73 443 251
UNIG6001000 600 1000 73 568 358
